Button Switch Drawing
Product Overview
The 16mm illuminated push button switches (Model: FLM16-FJ-1-CX000) from FILN are engineered for high-end industrial and commercial applications. These 16mm metal push button switches feature a unique concave head design with an even ring-light LED indicator, providing both a futuristic aesthetic and clear status feedback in low-light environments. Manufactured from premium stainless steel or anodized aluminum (Silver/Black), they carry global certifications including ISO9001, CE, VDE, RoHS, SGS, UL, and IP65. Ideal for industrial control panels, marine systems, and automation equipment, these switches ensure reliable circuit control with their 5-pin terminal design.
Quick Specifications
| Model | FLM16-FJ-1-CX000 |
| Mounting Hole Size | 16mm (0.63 inch) |
| Function | Latching / Momentary (Customizable) |
| LED Color | R / G / Y / B / W (Support Dual/Tri-color) |
| Button Shape | Concave Head (Flush mount effect) |
| Terminal Type | 5-PIN Pin Terminal (2.8x0.5mm) |
Performance Parameters
| Rated Voltage | 36V DC / 250V AC | Rated Current | 5A DC / 5A AC |
| Insulation Strength | 1800V | Contact Resistance | < 50mΩ |
| LED Voltage | 3V - 220V (12V/24V Standard) | Certifications | ISO9001, CE, VDE, RoHS, UL |
Component Materials
| Actuator | 304 Stainless Steel / 6063 Aluminum Alloy |
| Body Shell | H59 Brass / 304 Stainless Steel / 6063 Aluminum |
| Contact Material | Silver Alloy AgCdO12 |
| Base | PA66+GF20% Flame Retardant Nylon |
General Characteristics
| Operating Temp | -25°C to +85°C |
| Protection Level | IP65 Waterproof, IK08 Impact Resistance |
| Mechanical Life | 500,000 Cycles |
| Electrical Life | 100,000 Cycles (3A) / 50,000 Cycles (5A) |
Key Features
- Superior Durability: Rated IP65 and IK08, these switches handle outdoor environments and high-intensity mechanical impacts effortlessly.
- High Current Load: Unlike standard 2A switches, this 16mm model supports 5A 250V AC/DC, allowing direct control of higher-power devices without extra relays.
- Premium Contact Design: Equipped with AgCdO12 silver contacts to ensure low contact resistance (<50mΩ) and anti-arcing performance.
- Aesthetic Concave Head: The recessed button design prevents accidental triggers while the ring LED provides uniform illumination for high-tech aesthetics.
- Efficient Pin Terminals: Standard 2.8x0.5mm terminals support both soldering and quick-connect wire harnesses, ideal for mass production.
LED Color Application Guide
| Color | Typical Industry Meaning |
|---|---|
| Red | Emergency Stop, Warning, or Power Failure status. |
| Green | Normal Operation, System Ready, or Start status. |
| Blue | Auxiliary function, Reset, or Specialty machine state. |
| Yellow/Amber | Caution, Standby, or Non-critical maintenance required. |
| White | Neutral status, Backlight mode, or Power On indicator. |
Terminal Type Comparison
| Feature | Pin Terminal (This Model) | Screw Terminal | Pre-wired Button |
|---|---|---|---|
| Installation Speed | Fast (with sockets) | Moderate | Fastest |
| Connection Security | High (Soldered) | High (Tightened) | Moderate |
| Maintenance | Easy replacement | Manual rewiring | Replace whole unit |
Applications
These illuminated power buttons are versatile and widely used in CNC machines, marine-grade waterproof control panels, and medical devices. Any device requiring a reliable circuit toggle can benefit from the waterproof led indicator switch design.
Installation Guide
- Drill a hole of exactly 16mm on your control panel.
- Insert the switch actuator through the hole from the front.
- Secure the switch from the back using the provided metal hex nut and rubber gasket.
- Connect your 12v-24v power source and load to the 5-PIN terminals following the wiring diagram.
5-PIN LED Push Button Switch Wiring Guide
A 5-PIN switch offers maximum flexibility, featuring C (Common), NO (Normally Open), NC (Normally Closed), and two dedicated LED pins (+ / -). This allows for four distinct control modes. These switches can also be used with dedicated wire harnesses for even faster installation.
1. Normal OFF, Sync LED (NO Connection)
Logic: Both the device and the LED are OFF by default. Pressing the button turns ON the device and the LED simultaneously.
- Application: Standard start switches where the light indicates the system is running.
- State: Static (LED Out, Device Off) → Pressed (LED On, Device On).
2. Normal ON, Sync LED (NC Connection)
Logic: Both the device and the LED are ON by default. Pressing the button turns OFF both the device and the LED.
- Application: Stop buttons or emergency cut-off switches.
- State: Static (LED On, Device On) → Pressed (LED Out, Device Stop).
3. Normal OFF, Constant LED (NO Connection)
Logic: The LED stays ON constantly as a backlight. The device only turns ON when the button is pressed.
- Application: Power switches in dark environments or access control buttons.
- State: Static (LED On, Device Off) → Pressed (LED On, Device On).
4. Normal ON, Constant LED (NC Connection)
Logic: The LED stays ON constantly. The device is ON by default and turns OFF when the button is pressed.
- Application: Monitoring systems or security alarms that require constant power indication.
- State: Static (LED On, Device On) → Pressed (LED On, Device Stop).
| Mode | LED Behavior | Device (Idle) |
|---|---|---|
| NO Sync | Lights up when pressed | OFF |
| NC Sync | Turns off when pressed | ON |
| Constant | Always ON (Backlight) | User Choice |
Industry Knowledge
What are Illuminated Push Button Switches?
In industrial systems, these switches serve as the primary human-machine interface (HMI). They combine the physical mechanical action of a switch with an electrical status light. This reduces the need for separate indicator lamps on a panel, saving space and improving operator response time.
Latching vs. Momentary: The Difference
| Type | Action Description | Typical Use Case |
|---|---|---|
| Latching | Press to stay ON, press again to pop back OFF. | Power Switch, Lighting |
| Momentary | ON only while being held; returns to OFF once released. | Horns, Door Bells, Reset |
Factory Direct Supply
FILN is a specialized manufacturer with over 15 years of experience in custom color ring light switch production. We provide:
- No MOQ: Small orders and prototypes are welcome.
- Fast Delivery: Global shipping from our factory warehouse.
- Customization: Voltage (3V-220V), Laser Engraving, and Wire Harnessing.
Frequently Asked Questions
1. Is this 16mm metal push button switch waterproof?
Yes, it is IP65 rated, meaning it is protected against dust and low-pressure water jets from any direction.
2. Can I use this for a 220V AC circuit?
Yes, our switches support up to 250V AC with a 5A current rating.
3. What is the benefit of the concave head?
The concave head provides a comfortable tactile feel and helps prevent accidental activation.
4. Does the LED require a resistor?
No, the resistors are built into the switch body to support your specified voltage (e.g., 12V or 220V).
5. What materials are available?
We offer 304 Stainless Steel, H59 Brass, and Anodized Aluminum (Black/Silver).
6. Can you pre-wire the switch with a connector?
Yes, as a factory, FILN provides wire length and connector customization services.
7. What does IK08 mean?
It represents the level of protection against mechanical impacts, ensuring the switch won't break under industrial vibrations or accidental hits.
8. Is there a difference between the 5-pin and 4-pin versions?
The 5-pin version includes an NC (Normally Closed) terminal, offering more circuit control options than the 4-pin version.
9. How long is the mechanical life?
It is rated for 500,000 cycles, providing years of maintenance-free operation.
10. Do you provide samples for B2B testing?
Yes, please contact our sales team at inquiry@cnylin.com.cn for free samples.
