FILN 8mm 6V blue LED pilot Light Indicator Lights

$2.20
Shipping calculated at checkout.
DESCRIPTION
Product Item FL1M-8FJ-1
Panel Mount Diameter 8mm
Contact Way solder pin
Install Way screw terminal
Lamp Type LED
Rated voltage AC/DC,3V、6V、12V、24V、220V、380V
Lamp Color red yellow blue green white
Product Design flathead
Shell Material brass plated nickel/stainless steel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances,    automobiles, medical equipment, industrial equipment, etc
Component name material
lens PC plastic
Metal Body H59 brass or 304 stainless steel
Washer T10 Cold Rolled Steel
Rubber Ring SIL silica gel
Nut H59 nickel-plated brass
Housing PA66 nylon
Light Source LED
Resistor Metal film
Cable Pvc AWG22 0.3mm²
Plug-in C2680 RoHS brass
Items Parameter
Rated Voltage 3V-780V DC or AC
Rated Current 20mA
Rated Power 0.2W
Insulation and Voltage Resistance 1800V
Working Life 100000h
Electrical Life 100000
Cold-resistant -40℃
Heat-resisting 80℃



blue indicator light

Features of blue indicator light

Blue indicator light model is FL1M-08FJ-1, its opening is 8mm, the head is flat, the shell is nickel-plated copper, built-in high-brightness LED lamp beads, the production voltage is 6V, 12V, 24V , 120V, 220V, LED colors are red, green, yellow, blue and white, the tail is made of flame-retardant and high temperature resistant nylon PA66 material, and the terminal uses 2.8x0.5mm fast terminal.


 FILN 8mm 6V blue LED pilot Light Indicator Lights product introduction

 FILN 8mm 6V blue LED pilot Light Indicator Lights are novel in shape, clear light-emitting parts, energy-saving and power-saving, long service life, suitable for all kinds of small household appliances, electronic equipment, automation equipment, instrumentation, communication equipment, car modification, motorcycles, For photography, toys, refrigerators, freezers, electric welders, generators, medical equipment and other electrical circuits, it is used for various light indicator signals, warning signals, accident signals and other signals.




 How to wire a blue indicator light ?

The blue indicator light produced by FILN uses non-polar two-way high-brightness LEDs internally. In actual use, there is no distinction between positive and negative poles and can be welded arbitrarily.




What are the advantages of FILN's production of blue indicator light?

1.8mm led indicator light uses a copper shell and a ring-shaped electroplating process. The outsourcing is translucent, has anti-oxidation, anti-corrosion, and has a long service life. It can also be made of 304,316 stainless steel according to customer needs, and aluminum alloy can also be produced. For oxidized materials, shells of various colors can be produced, and there is no quantitative requirement.

2.6 volt LED indicator light The built-in high-brightness LED, low power consumption, high brightness, long service life, and built-in integrated resistance, customers can use it directly after buying it back, no additional resistance is required, and other voltages are available Production.

3.The base of the blue LED indicator lights is made of nylon material with fire rating V-0, which is safer in use.

4.Pilot light indicator lampshade material: PC material with high light transmittance, good light transmittance and mild color.

5.FILN 8mm 6V blue LED pilot Light Indicator Lights certificate is complete, currently we have UL, CE, ROHS, waterproof rating.


How to buy Blue indicator light ?

 FILN 8mm 6V blue LED pilot Light Indicator Lights are 100 pcs in a box, 2000 pcs is a box, 100 pcs weight is 1KG, if you need a small amount of blue indicator light, you can place an order directly at our shop, we have all in stock, and accept Delivery can be arranged immediately upon order.

If you have customized requirements, or peripheral matching wiring harnesses, you can write your requirements, such as pre-connected wires, or pre-installed customized quick-connect terminals, or special voltages.

 FILN company has 20 years of experience in the production of FILN 8mm 6V blue LED pilot Light Indicator Lights, as well as a professional ship switch research and development team, which can customize the ship switch solution for you within 24 hours. FILN company also has more than 10 years of overseas sales experience , Can communicate and solve international trade problems in time, if there is any question about ship type switch.



ADDITIONAL INFORMATION
Color: Blue, Purple, White
Size: 20, 24
Material: 100% Polyester
