12MM Metal 240V LED Indicator Light With Wire Colour
12MM Metal 240V LED Indicator Light With Wire Colour
12MM Metal 240V LED Indicator Light With Wire Size
12MM Metal 240V LED Indicator Light With Wire Red
12MM Metal 240V LED Indicator Light With Wire Back
12MM Metal 240V LED Indicator Light With Wire Red
12MM Metal 240V LED Indicator Light With Wire Blue
12MM Metal 240V LED Indicator Light With Wire Detail
12MM Metal 240V LED Indicator Light With Wire Red
12MM Metal 240V LED Indicator Light With Wire White

12MM Metal 240V LED Indicator Light With Wire

Product Drawing The mounting dimension of the 240V LED indicator light is 12mm, that’s 0.472 inches. The...
$2.26
$2.26
Please hurry! Only 2000 left in stock
Color: RED
Voltage: 6V
Subtotal: $2.26
10 customers are viewing this product

Shipment by DHL

Enjoy points to reduce shipping fees

Free Returns

Learn More.

Built And Shipped Within 5 - 7 Bussiness Days

12MM Metal 240V LED Indicator Light With Wire Red

12MM Metal 240V LED Indicator Light With Wire

$2.26

12MM Metal 240V LED Indicator Light With Wire

$2.26
Color: RED
Voltage: 6V

Product Drawing

12MM Metal 240V LED Indicator Light With Wire Drawing

The mounting dimension of the 240V LED indicator light is 12mm, that’s 0.472 inches. The opening dimension is between 12.2mm to 12.5mm.

240V LED Indicator Light Detailed Parameters

Component Name Material
Lens PC Plastic
Metal Body H59 Brass Or 304 Stainless Steel
Washer T10 Cold Rolled Steel
Rubber Ring SIL Silica Gel
Nut H59 Nickel Plated Brass
Housing PA66 Nylon
Light Source LED
Resistor Metal Film
Cable PTFE AWG22 0.3mm²
Items Parameter
Rated Voltage 3V-780V DC Or AC
Rated Current 20MA
Rated Power 0.2W
Insulation And Voltage Resistance 1800V
Working Life 100,000H
Electrical Life 100,000
Cold-resistant -40℃
Heat-resisting 80℃
Plug-in C2680 ROHS Brass

Product Item FL1M-12FW-2
Panel Mount Diameter 12MM
Contact Way With Wire
Install Way Screw Terminal
Lamp Type LED
Rated Voltage AC / DC, 3V, 6V, 12V, 24V, 220V, 380V
Lamp Color Red,Yellow, Blue, Green, White
Product Design Flat Head
Shell Material Brass Plated Nickel / Stainless Steel
Base Material PA66 Nylon
Terminal Material Brass
Applications Coffee machine, Kitchen equipment, Household appliances, Automobiles, Medical equipment, Industrial equipment etc.
